Features
Avg. Lift Capacity (Less Attachment)
8500 lbs @ 10’
Boom Data
22’ Knuckle Boom extensions to 28’
Lightweight high strength steel
2-1/2” high strength pivot pins
Aluminum bronze pivot bushings
Boom Cylinders
(1) 5-1/2” x 36” x 3”
(1) 5” x 35-1/2” x 2-1/2”
Double acting with ductile iron internal components and hard chrome plated shafts
Rotation
Continuous rotation, 27” rotation bearing powered by a single hydraulic motor and planetary gearbox
Stabilizers
Telescoping A-frame type, 117-3/4” spread at grade level
Double acting 3-1/2” x 44” x 2” cylinders
Hydraulics
Tandem hydraulic system providing 30 & 30 GPM
Stack type control valves with joystick controls
50 gallon A-frame reservoir
