Features
Avg. Lift Capacity (Less Attachment)
7000 lbs @ 10’
Boom Data
20’ Knuckle Boom extensions to 25’
Lightweight high strength steel
2” high strength pivot pins tapered roller bearings
Boom Cylinders
5” x 30” x 2-1/2”
Double acting with ductile iron internal components and hard chrome plated shafts
Rotation
600 degree non-continuous, mechanical stops
26” rotation bearing powered by a single hydraulic motor and planetary gearbox
Stabilizers
Telescoping A-frame type, 110-5/8” spread at grade level
Double acting 3” x 40” x 2” cylinders
Hydraulics
Tandem hydraulic system providing 30 & 30 GPM
Stack type control valves with joystick controls
55 gallon reservoir
